ZB Hydraulic Oil Pump
Category:
Hydraulic Pump
Keywords：
Electric Hydraulic Pump
High Pressure Hydraulic Pump
high pressure electric oil pump
Description
ZB2x2-50 ultra-high pressure electric oil pump is an independent and complete hydraulic power unit composed of piston pump, control valve, oil tank, motor, instrumentation and so on. It is characterized by high working pressure, simple structure and easy operation.
With special tools, it can realize lifting, bending, straightening, extruding, scissoring, riveting, dismantling, press fitting and other work requirements, and as a hydraulic power unit, it can also be installed in other mechanical equipment. This pump can realize the shutdown pressure preservation, under the condition of no leakage in the external oil circuit, the shutdown pressure preservation is 5 minutes, and the pressure drop is not more than 5MPa.
| Technical parameters of ZBZ2x2-50A Series oil pump | |||||
| Plunger | Diameter(mm) | 10 | Motor | Model Number | Y100L2-4 B5 |
| Stroke (mm) | 9 | Power | 3.0kw | ||
| Quantity (PCS) | 2*3 | Rotating speed | 1430r/min | ||
| Oil pump Rotating speed | 1430r/min | Oil outlet (PCS) | 2 | ||
| Theoretical displacement | 3.5 ml/r | Usage Oil Type | Hot Temp. N40 Machinery oil | ||
| Cold Temp. N20 Machinery oil | |||||
| Nominal Oil Pressure | 50 (63) MPa | Weight(KG) | 100 | ||
| Nominal Flow (L/Min) | 2*2 | Oil Tank Capacity | 45L | ||
More than 20 years of rich experience
in the productiong technology of Prestressed industry
DAFANG Prestressed is a professional manufacturer and a Supplier engaged in research, development, production, sale, and service of hydraulic tension jack, hydraulic oil pump, post-tension anchorage, pc strand, and intelligent tension systems.
DAFANG Prestressed is dedicated to strict quality control and thoughtful customer service, experienced specialists are always available to discuss your requirements and ensure full customer satisfaction.
In recent years, DAFANG Prestressed has added a series of advanced equipment including CNC machine tool, CNC rocker drill, CNC drilling machine, and CNC cutting machine.
All products are selling well in both domestic and abroad. Products have been exported to clients in many countries and regions such as Cambodia, Malaysia, Philippines, Dubai, and Colombia.
